    Fluke PM6303 - RCL Meter

    Značka: Fluke

    RCL Meter

    Effective, economic testing that"s quick and easy to use

    The PM 6303A is quick and simple to operate, on the manufacturing floor as a quality assurance tool or in the service lab for quick tests of a wide variety of components. Its simple operation and 0.25% basic accuracy make the PM 6303A equally at home in the classroom for education and training environments.

    Položka bola vypredaná…
    Dostupnosť Na objednávku
    Môžeme doručiť do:
    9.1.2026
    Možnosti doručenia
    Kód: 1957
    €1 €0,81 bez DPH
    Fluke PM6303 - RCL Meter
    Značka: Fluke
    Fluke PM6303 - RCL Meter
    Ukončená výroba
    Doprava zadarmo pre každý nákup nad 80€ s DPH vytvorený cez náš eshop s doručením na Slovensko.
    Doprava zadarmo
    pre každý nákup nad 80€ s DPH vytvorený cez náš eshop s doručením na Slovensko.
    Široké možnosti platby na dobierku, kartou online alebo bankovým prevodom.
    Široké možnosti
    platby a doručenia pre vaše pohodlie. Prijímame platobné karty, Google Pay alebo Apple Pay.
    Tovar skladom odosielame v deň objednávky (do 13:00)
    Tovar skladom
    odosielame v deň objednávky kuriérom SPS alebo službou Packeta (objednávky do 13:00).
    Záručný, pozáručný servis teplomerov, multimetrov a iného metrologického vybavenia.
    Servis a kalibrácia
    teplomerov, multimetrov a iného metrologického vybavenia vrátane záručného a pozáručného servisu.

    PM 6303A/01 RCL Meter (1kHz)

    Technical Specifications
    AC test mode
    Test frequency: 1 kHz
    Test frequency accuracy: 0.025%
    Test signal level: 2V via 400Ω source
    Basic measurement accuracy: 0.25% ± 1 digit
    DC bias
    Internal: 2V
    Maximum measurement ranges
    Impedance/Resistance Z or RAC: 0.000Ω to 200 MΩ
    Capacitance C: 0.0 pF to 100 mF
    Inductance L: 0.0 mH to 32 kH
    Quality factor Q: : 0.0002 to 500
    Dissipation factor D: 0.002 to 500
    Phase angle F: -90.0 to +90.0 deg
    Maximum resolution
    Impedance/Resistance Z or RAC: 01 MΩ
    Capacitance C: 0.1 pF
    Inductance L: 0.1 mH
    Quality factor Q: 0.001
    Dissipation factor D: 0.001
    Phase angle F: 0.1 deg
    Circuit diagram
      7 different equivalent circuit diagrams
    Auto mode
    Read-out: Dominant parameter
    Equivalent circuit diagram: Parallel for R+C
      Serial for R+L
    Manual Mode
    Read-out: Dominant or secondary parameter
    Equivalent circuit diagram: Parallel or serial selectable
    Measurement update rate
      2 measurements/s
    Trim function
    Open circuit: Open circuit compensation
      Z > 100 kΩ
    Short circuit: Short circuit compensation
      Z < 10Ω
    Stored settings (non-volatile memory)
    Front panel settings: 1 (trim figures included)
    Calibration Interval
      1 year
    Environmental Conditions
    Operating temperature: 0°C to 50°C
    Storage temperature: -40°C to 70°C
    Power requirements: 100/120/220/240V ± 10%
    Line frequency: 50 to 100 Hz
    Power consumption: 16 VA
    Safety: According to CE-regulation 73/23 EN61010-1 CAT II, Pollution Degree 2
    EMC: According to CE regulation 89/336: Emission according to EN 55011, Group 1 Class B, respectively CISPR 11. Immunity according to EN 50082-1, inclusive IEC 801-2, -3, -4
    Warm-up time: 5 minutes
    Dimensions and weight
    W x H x D: 315 x 105 x 401 mm (12.4 in x 4.13 in x 15.9 in)
    Weight: 3.8 kg (8.4 lb)
