TTi EX354Tv - Kompaktný laboratórny stabilizovaný zdroj DC 35V/4A (305W)

Trojitý stolný zdroj. 305W

Dostupnosť Opýtajte sa
Možnosti doručenia
Kód: 946
€1 €0,83 bez DPH
TTi EX354Tv - Kompaktný laboratórny stabilizovaný zdroj DC 35V/4A (305W)
TTi EX354Tv - Kompaktný laboratórny stabilizovaný zdroj DC 35V/4A (305W)
Ukončená výroba
Doprava zadarmo pre každý nákup nad 80€ s DPH vytvorený cez náš eshop s doručením na Slovensko.
Doprava zadarmo
pre každý nákup nad 80€ s DPH vytvorený cez náš eshop s doručením na Slovensko.
Široké možnosti platby na dobierku, kartou online alebo bankovým prevodom.
Široké možnosti
platby a doručenia pre vaše pohodlie. Prijímame platobné karty, Google Pay alebo Apple Pay.
Tovar skladom odosielame v deň objednávky (do 13:00)
Tovar skladom
odosielame v deň objednávky kuriérom SPS alebo službou Packeta (objednávky do 13:00).
Záručný, pozáručný servis teplomerov, multimetrov a iného metrologického vybavenia.
Servis a kalibrácia
teplomerov, multimetrov a iného metrologického vybavenia vrátane záručného a pozáručného servisu.

Tento výrobok je zmenený na EX354RT.





EX series - high power at low cost
The EX series provides high levels of power at surprisingly low cost.
The attractive case style is highly compact using the minimum of bench space. The fan-less design provides silent operation *. The low weight makes them easy to move about.

Mixed-mode regulation
The EX series combines switch-mode pre-regulation with linear post-regulation to provide performance comparable with an all linear design.
Excellent line and load regulation is matched by low noise and good transient response. High power efficiency makes fan cooling unnecessary.

Constant voltage or constant current
The main outputs can operate in constant voltage or constant current mode with automatic crossover and mode indication. Coarse and fine voltage controls are provided. The current control is logarithmic enabling low current levels to be set accurately.

Auxiliary low-voltage output
The EX354Tv incorporates a third output variable between 1.5V and 5.0V with a fixed current limit of 5A. The set voltage can checked using the digital displays.


Simultaneous digital metering
The EX series incorporate separate digital voltage and current meters on each main output. The meters use bright 14mm (0.56") LED displays and have an update rate of 4 per second providing near instantaneous response.
Simultaneous metering of voltage and current provides accurate information “at a glance” and avoids any possibility of misinterpretation.
When an output switch is set to “off”, the current limit setting is displayed enabling conditions to be set before the load is connected.

Safety and reliability
The EX series has been designed to meet the stringent requirements of relevant IEC standards for safety and EMC. All outputs are intrinsically short circuit proof, and are protected against external voltages and reverse currents.

MAIN OUTPUTS
Operating Mode Constant voltage or constant current with automatic cross-over and indication.
Voltage Setting 0V to >rated O/P by coarse and fine controls.
Current Setting 0A to >rated O/P by single logarithmic control.
Load regulation <0.01% of max. O/P for a 90% load change.
Line regulation <0.01% of max. O/P for a 10% line voltage change.
Output impedance Typically <5mW in constant voltage mode. Typically >50kW in constant current mode.
Ripple & Noise
(20MHz bandwidth)
Typically <2mV rms (CV mode).
Transient Response <200µs to within 50mV of set level for 90% load change.
Temp. Coefficient Typically <100ppm/°C.
Output Protection Outputs will withstand forward voltages above the rated output voltage. Reverse protection by diode clamp for currents up to 3A.
Status Indication Output ON lamps. Constant current lamps.
Output Switch Electronic. Preset voltage and current displayed when output is off.
Output Terminals 4mm terminals on 19mm (0.75") pitch .
METERS (main outputs)
Meter Types Separate 3 digit meters for voltage & current with 14mm (0.56") LED displays. Reading rate 4/sec.
Meter Resolutions 100mV, 10mA.
Meter Accuracies Voltage 0.3% ±1 digit. Current 0.6% ±1 digit.
AUXILIARY LOW VOLTAGE OUTPUT (EX354Tv)
Voltage Variable <1.5V to >5V by front panel control.
Meter Voltage accuracy 0.3% ± 1 digit.
Current limit 5A minimum.
Load regulation <0.5% for a 90% load change.
Line regulation <0.1% for a 10% line voltage change.
Ripple & Noise
(20MHz bandwidth)
Typically <2mVrms, <10mVpk-pk (CV mode).
Output Protection Output will withstand up to 7V forward voltage. Diode clamp reverse protection for currents up to 3A.
Output Terminals 4mm terminals on 19mm (0.75") pitch .
Status Indication UNREG lamp.
POWER
AC Input EX354D, EX354Tv, EX752M: 110V to 240V ±10%, 50/60Hz.EX355, EX355P, EX1810R, EX4210R, : 220 to 240V ±10% (115V to order). Installation Category II.
SIZE AND WEIGHT
Size 140 x 160 x 320mm (single); 260 x 160 x 320mm (dual/triple)
Weight 3.0 to 4.4kg.
ENVIRONMENTAL
Operating Range +5°C to +40°C, 20% to 80% RH.
Storage Range -40°C to + 70°C.
Environmental Indoor use at <2000m, Pollution Degree 1.
Safety Complies with EN61010-1.
EMC Complies with EN61326.
