AC/DC Klieštový multimeter





Fluke 317/319 Clamp Meters

General Specifications
Digital Display
6000 digit resolution
Low Battery Indication
Low battery indication
Power Supply
3 x AAA IEC LR03 batteries
Clamp Opening Size
1.45 in (37 mm)
Jaw Diameter
1.45 in (37 mm)
Dimensions (L x W x H)
234 x 74 x 34.8 mm
6.39 in x 2.29 in x 1.20 in
Weight
384g (including batteries)
Automated measurement
Ohms
Safety
CE
EN/IEC 61010-1 and IEC 61010-2-032
Installation type III, 600V working environment
317 Electrical Specifications
Current AC
Range 40.00 A, 600.0 A
Resolution 0.01 A, 0.1 A
Accuracy 1.6% ± 6 digit (50-60 Hz) {40 A}
2.5% ± 8 digit (60-500 Hz) {40 A}
1.5% ± 5 digit (50-60 Hz) {600 A}
2.5% ± 5 digit (60-500 Hz) {600 A}
Crest Factor add 2% into spec for CF > 2 3.0 Max @ 500 A, 2.5 Max @ 600 A
AC response rms
Current DC
Range 40.00 A, 600.0 A
Resolution 0.01 A, 0.1 A
Accuracy 1.6% ± 6 digit (40 A)
1.5% ± 5 digit (600 A)
Voltage AC
Range 600.0 V
Resolution 0.1 V
Accuracy 1.5% ± 5 digit (20-500Hz)
AC response rms
Voltage DC
Range 600.0 V
Resolution 0.1 V
Accuracy 1% ± 4 digit
Resistance
Range 400.0 Ω, 4000 Ω
Resolution 0.1 Ω, 1 Ω
Accuracy 1% ± 5 digit
Continuity (Ω)
≤ 30 Ω
Inrush
Integration time N/A
Frequency (HZ)
Range N/A
Accuracy N/A
Trigger Level N/A
319 Electrical Specifications
Current AC
Range 40.00 A, 600.0 A, 1000 A
Resolution 0.01 A, 0.1 A, 1 A
Accuracy 1.6% ± 6 digit (50-60 Hz) {40 A}
2.5% ± 8 digit (60-500 Hz) {40 A}
1.5% ± 5 digit (50-60 Hz) {600/1000 A}
2.5% ± 5 digit (60-500 Hz) {600/1000 A}
Crest Factor add 2% into spec for CF > 2 3.0 Max @ 500 A, 2.5 Max @ 600 A, 1.4 Max @ 1000 A
AC response rms
Current DC
Range 40.00 A, 600.0 A, 1000 A
Resolution 0.01 A, 0.1 A, 1 A
Accuracy 1.6% ± 6 digit (40 A)
1.5% ± 5 digit (600/1000 A)
Voltage AC
Range 600.0 V
Resolution 0.1 V
Accuracy 1.5% ± 5 digit (20-500Hz)
AC response rms
Voltage DC
Range 600.0 V
Resolution 0.1 V
Accuracy 1% ± 4 digit
Resistance
Range 400.0 Ω
4000 Ω
Resolution 0.1 Ω
1 Ω
Accuracy 1% ± 5 digit
Continuity (Ω)
≤ 30 Ω
Inrush
Integration time 100 ms
Frequency (HZ)
Range 5.0 - 500.0 Hz
Accuracy 0.5% ± 5 digit
Trigger Level 10 - 100 Hz ≥ 5 A, 5 - 10 Hz, 100 - 500 Hz ≥ 10 A

All precisions refer to 73 °F ± 41 °F (23 °C ± 5 °C).
Less than 64 °F and greater than 82 °F (18 °C and greater than 28 °C)

Environmental Specifications
Operating Temperature
14°F to 122°F (-10 °C to 50 °C)
Storage Temperature
-40 °F to 140 °F (-40 °C to 60 °C)
Operating Humidity
Non condensing (< 50 °F) (< 10 °C)
90 % RH (50 °F to 86 °F) (10 °C to 30 °C)
75 % RH (86 °F to 104 °F) (30 °C to 40 °C)
45 % RH (104 °F to 122 °F) (40 °C to 50 °C)
Non-condensing
Operating Altitude
Altitude 2000 metres
Storage Altitude
Altitude12,000 metres
IP Rating
IP40
Vibration Requirements
Random MIL-PRF-28800F Class 2, 5-500 Hz, 30 minutes per axis
Drop Test Requirements
1m
EMI, RFI, EMC
Without special EMC environmental usage ≥ 0.1 V/m
Temperature Coefficients
0.1x (stipulated precision)/ °C
(<64 °F or > 82° F)
(<18 °C or > 28 °C)
